ORLACO
These cameras are available in several different viewing angles to suit the various applications they can be used in. For example, if you want to see details in a long way, choose a narrower opening angle and instead you want a cross-section view, choose a further opening angle. Orlaco cameras are suitable for all types of vehicles, regardless of whether you need a power camera, back camera or side camera.
Orlaco's new FAMOS camera is not gas-filled as the traditional clover camera has been before, but it's epoxy-filled instead. This has provided better protection against moisture.
Camera Angle | 170 |
---|---|
Image Format | PAL |
IP Class | IP68, IP69K |
Supply Voltage DC Max | 24 V DC |
Supply Voltage DC Min | 12 V DC |
Temperature range from | -40 °C |
Temperature range to | 85 °C |
Vibration Resistance | 50G |
These cameras are available in several different viewing angles to suit the various applications they can be used in. For example, if you want to see details in a long way, choose a narrower opening angle and instead you want a cross-section view, choose a further opening angle. Orlaco cameras are suitable for all types of vehicles, regardless of whether you need a power camera, back camera or side camera.
Orlaco's new FAMOS camera is not gas-filled as the traditional clover camera has been before, but it's epoxy-filled instead. This has provided better protection against moisture.
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Articles | Camera Angle | Image Format | ||
---|---|---|---|---|
![]()
CAMERA FAMOS 170 PAL
Art:
ORL0171070
Copied
|
170
|
PAL
|
| |
![]()
**PLEASE USE ORL0171001**
Art:
ORL0171000
Copied
|
129
|
PAL
|
| |
![]()
**PLEASE USE ORL0171011**
Art:
ORL0171010
Copied
|
118
|
PAL
|
| |
![]()
CAMERA FAMOS 118 PAL MIRROR
Art:
ORL0171210
Copied
|
118
|
PAL
|
| |
![]()
**PLEASE USE ORL0171021**
Art:
ORL0171020
Copied
|
102
|
PAL
|
| |
![]()
CAMERA FAMOS 102 PAL MIRROR
Art:
ORL0171220
Copied
|
102
|
PAL
|
| |
![]()
CAMERA FAMOS 102 PAL SW
Art:
ORL0171250
Copied
|
102
|
PAL
|
| |
![]()
**PLEASE USE ORL0171031**
Art:
ORL0171030
Copied
|
80
|
PAL
|
| |
![]()
**PLEASE USE ORL0171041**
Art:
ORL0171040
Copied
|
60
|
PAL
|
| |
![]()
**PLEASE USE ORL0171051**
Art:
ORL0171050
Copied
|
40
|
PAL
|
| |
![]()
**PLEASE USE ORL0171061**
Art:
ORL0171060
Copied
|
20
|
PAL
|
| |
![]()
**PLEASE USE ORL0171101**
Art:
ORL0171100
Copied
|
129
|
NTSC
|
| |
![]()
**PLEASE USE ORL0171111**
Art:
ORL0171110
Copied
|
118
|
NTSC
|
| |
![]()
Camera FAMOS 118 ° NTSC MIRROR
Art:
ORL0171230
Copied
|
118
|
NTSC
|
| |
![]()
**PLEASE USE ORL0171121**
Art:
ORL0171120
Copied
|
102
|
NTSC
|
| |
![]()
**PLEASE USE ORL0171131**
Art:
ORL0171130
Copied
|
80
|
NTSC
|
| |
![]()
**PLEASE USE ORL0171141**
Art:
ORL0171140
Copied
|
60
|
NTSC
|
| |
![]()
**PLEASE USE ORL0171151**
Art:
ORL0171150
Copied
|
40
|
NTSC
|
| |
![]()
**PLEASE USE ORL0171161**
Art:
ORL0171160
Copied
|
20
|
NTSC
|
|
Select a variant in the list
