| IP Class | IP64 |
|---|---|
| Shaft Diameter | 10 mm |
| Connection Thread | Screw terminal |
| Temperature range to | 85 °C |
| Housing diametre | 58 mm |
| Temperature range from | -40 °C |
| Version | Multiturn |
| Supply Voltage DC Max | 30 V DC |
|---|---|
| Output | Profibus |
| Supply Voltage DC Min | 10 V DC |
| Speed max. | 6000 rpm |
| Sensor type | Absolute |
| Resolution | Max. 13 bit resoluutiolle ja 12 bit kierroksille |
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Articles | IP Class | Shaft Diameter | Connection Thread | Temperature range to | Housing diametre | Temperature range from | Version | Supply Voltage DC Max | Output | Supply Voltage DC Min | Speed max. | Sensor type | Resolution | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Absolute encoder, Profibus
Art:
MHM510-PROF-001
Copied
|
IP64
|
10 mm
|
Screw terminal
|
85 °C
|
58 mm
|
-40 °C
|
Multiturn
|
30 V DC
|
Profibus
|
10 V DC
|
6000 rpm
|
Absolute
|
Max. 13 bit resoluutiolle ja 12 bit kierroksille
|
| |
|
Absolute encoder, CANopen
Art:
MHM510-CANO-001
Copied
|
IP64
|
10 mm
|
Screw terminal
|
85 °C
|
58 mm
|
-40 °C
|
Multiturn
|
30 V DC
|
CANopen
|
10 V DC
|
6000 rpm
|
Absolute
|
Max. 13 bit resoluutiolle ja 12 bit kierroksille
|
| |
|
Absolute encoder, DeviceNet
Art:
MHM510-DNET-001
Copied
|
IP64
|
10 mm
|
Screw terminal
|
85 °C
|
58 mm
|
-40 °C
|
Multiturn
|
30 V DC
|
Device-Net
|
10 V DC
|
6000 rpm
|
Absolute
|
Max. 13 bit resoluutiolle ja 12 bit kierroksille
|
|
Select a variant in the list
