| IP Class | IP65 |
|---|---|
| Shaft Diameter | 14 mm |
| Connection Thread | M23 contact |
| Temperature range to | 90 °C |
| Housing diametre | 58 mm |
| Temperature range from | -20 °C |
| Version | Singleturn |
| Supply Voltage DC Max | 30 V DC |
|---|---|
| Output | SSI |
| Supply Voltage DC Min | 5 V DC |
| Speed max. | 6000 rpm |
| Sensor type | Absolute |
| Resolution | Max. 20 bit |
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Articles | IP Class | Shaft Diameter | Connection Thread | Temperature range to | Housing diametre | Temperature range from | Version | Supply Voltage DC Max | Output | Supply Voltage DC Min | Speed max. | Sensor type | Resolution | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Absolute encoder, SSI, binary, M23 connector
Art:
CHO514PCSB13S6R
Copied
|
IP65
|
14 mm
|
M23 contact
|
90 °C
|
58 mm
|
-20 °C
|
Singleturn
|
30 V DC
|
SSI
|
5 V DC
|
6000 rpm
|
Absolute
|
Max. 20 bit
|
| |
|
Absolute encoder, SSI, gray, M23 connector
Art:
CHO514PCSG13S6R
Copied
|
IP65
|
14 mm
|
M23 contact
|
90 °C
|
58 mm
|
-20 °C
|
Singleturn
|
30 V DC
|
SSI
|
5 V DC
|
9000 rpm
|
Absolute
|
Max. 20 bit
|
|
