PULS

FIEPOS eFuse

100-240 V AC/24-28 V DC, 300 and 500 W

The FPS300 is an industrialgrade power supply for 1-phase networks incorporated in to a rugged wall- mount housing with IP65/67 protection.

It provides two to four stabilized outputs that is galvanically separated from the input.

The negative potential of the outputs is permanently connected to PE within the unit.

The most outstanding features of the FPS series are the compact size, the wide operational temperature range, the extremely low input inrush current and the very high efficiencies, which are achieved by various design technologies.

Large sized output capacitors can absorb and store regenerative energy from breaking motors.

Read more
  • IP65/IP67
  • Up to 4 switchable outputs
  • Output power 360/600 W
  • 600/1000 Wpeak 5s
  • IO-Link or DC-OK relay

Selected variant


IP65/IP67 Power supply 100-240VAC/24VDC, 300W

Art:

Selected variant

Specifications

Power Consumption At 120 V AC 3,2 A
Input voltage AC 100-240 V
Input voltage ac min 85 V AC
Input voltage dc max 360 V DC
Input voltage DC 110-300 V
Input voltage ac max 264 V AC
Number of phases 1
Inrush current at 230 V ac typical 6 A
Power Consumption At 230 V AC 1,68 A
Supply Frequency 50-60 Hz ±6 %
Inrush current at 120 V ac typical 3 A
Power Factor at 120 V AC, full load. Typical 0,99
Power Factor at 230 V AC, full load. Typical 0,97
Input voltage dc min 88 V DC
Back-feeding loads 35V / 4 J
Ripple. max 50 mV pp
Output voltage min 24 V DC
Total output power <+55°C 300 W
Total output power <5 s, <+55°C 600 W
Output Current per channel 10 A
Temperature Range Without Derating From -25 °C
Total output power <5 s, <+70°C 300 W
Output voltage 24 V DC
Total output power <+45°C 360 W
Output voltage max 28 V DC
Effect 300 W
Temperature Range Without Derating To 55 °C
Total output power <+70°C 150 W
Power drop from +55 °C to + 70 °C 10 W/°C
Efficiency At 230 V AC, full load. Typical 95,7 %
Efficiency At 230 V AC. Typical 94,6 %
Efficiency At 120 V AC, full load. Typical 94,3 %
Weight 1,2 kg
Depth 59 mm
Width 182 mm
Height 183 mm
DC-OK/IO-link connector M12-A
Input connector 7/8"
Output connectors 1x 7/8"
IP Class IP65, IP67
DC relay output No
Hold-up time at 120 V AC, full load. Typical. 37 ms
IO-LINK Yes
Series FIEPOS eFuse
Hold-up time at 230 V AC, full load. Typical. 37 ms
Approvals CB, CE, UKCA, cULus
Material Protection Aluminium
Active Transient Yes

Product description

The FPS300 is an industrialgrade power supply for 1-phase networks incorporated in to a rugged wall- mount housing with IP65/67 protection.

It provides two to four stabilized outputs that is galvanically separated from the input.

The negative potential of the outputs is permanently connected to PE within the unit.

The most outstanding features of the FPS series are the compact size, the wide operational temperature range, the extremely low input inrush current and the very high efficiencies, which are achieved by various design technologies.

Large sized output capacitors can absorb and store regenerative energy from breaking motors.
